super-uaEFI¶
A sibling of uaefi121 with STM32F7 for larger Lua scripts and motorsports superseal headers available at 💲rusEFI store💲
🔴 Community support ONLY 🔴 Support Statement 🔴 Facebook group 🔴 Discord 🔴
super-uaEFI Release Software super-uaEFI Beta Snapshot Release vs Snapshot
Specs¶
- ⏩ Interactive Pinout ⏪
- One of the eight universal units we offer
- Sequential 8 cylinder injection
- Sequential six injector outputs for more complex engines
- Capable of driving 8 sequential injector outputs on simpler engines
- Smart coils by default, expandable with on-board IGBT igniters to drive legacy coils
- Six additional low side outputs
- Dual on-board 4.9 WBO controller
- Dual Drive By Wire electronic throttle body
- One 2A high side output
- Two VRs: one MAX9924 one VR-discrete
- Knock sensor input
- 120 pin supersealheader
- On-board digital baro sensor
- 7+2 analog inputs
- Optional on-board EGT
- Optional on-board MAP sensor
- Comes WITHOUT waterproofing considerations - please add your own potting!
- Matching USB cap sold separately
- option to use on-board removable SD card
- Looking for proper 8 cylinder sequential ignition? that's https://www.shop.rusefi.com/shop/p/rusefi-huge
Harness Connectors¶
| TE | |
|---|---|
| A plug | 4-1437290-0 |
| B plug | 3-1437290-7 |
| C plug | 4-1437290-1 |
| D plug | 3-1437290-8 |
Enclosure¶
If you got naked you can print your own see https://github.com/rusefi/rusefi_documentation/tree/master/Hardware-files/Hellen/super-uaefi
